Trailer Parts Pro EB01-162 Trailer Parts Pro 16000 lbs Per Pair Capacity 8000 lbs Each Forward Self Adjust 12-14in x 5in Electric Drum Trailer Brake Left Side 7-Bolt Mount Black Painted Finish Boxed
Brands:
Product Number: DEX-EB01-162
Vendor Number: EB01-162
$181.99
$164.99

Trailer Parts Pro EB01-162 Trailer Parts Pro 16000 lbs Per Pair Capacity 8000 lbs Each Forward Self Adjust 12-14in x 5in Electric Drum Trailer Brake Left Side 7-Bolt Mount Black Painted Finish Boxed
Brands:
Product Number: DEX-EB01-162
Vendor Number: EB01-162
$181.99
$164.99
You Save $17.00 (9.3%)
Attention Customers:
The items we have listed for pop up campers are the only items we have available. We are not able to special order any items at this time, and we are unable to provide technical assistance due to high order volume.
For product availability, please text (855) 432-6357 with the vendor number and quantity you are looking for. We will answer ASAP.
People Also Shop

WH155-545SM Wheel Only 15 X 5 Steel Silver Modular Wheel With 5 Holes On 4-12 Centers Bolt Pattern …
REG. $63.99
Sale! - $63.99
Free Shipping
Trailer Parts Pro EB01-162 Trailer Parts Pro 16000 lbs Per Pair Capacity 8000 lbs Each Forward Self Adjust 12-14in x 5in Electric Drum Trailer Brake Left Side 7-Bolt Mount Black Painted Finish Boxed
Product Details
12-1/4in x 5in 12,000lbs(7 bolt flange) Left hand electric brake. Complete assembly. Features: Self-adjusting design keeps shoes properly aligned for longer-lasting brake that requires less maintenance. Mounts with 7 bolts (not included).
Nuts-6-17, bolts-7-116, and washers-5-8are sold separately.
These components have passed the CSA Standard CAN3-D313-M85 For Trailer Running Gear, a stringent standard mandated by the Government to assure brake effectiveness and structural integrity of the components.
ISO/TS 16949:2002 certified
» Was redesigned with forward self-adjusting feature in June 1996.
» Was redesigned with a cast backing plate in May 2000 replacing the stamped version.
• Fits Dexter 12,000lb axles(with cast backing and 7 bolt flange)
• For use with a 12 1/4in inside diameter and 5in depth drum
• Shoes are 5in wide
• Self-adjusting
• Left hand(driver's side)
• Complete assembly ready to install
Nuts-6-17, bolts-7-116, and washers-5-8are sold separately.
These components have passed the CSA Standard CAN3-D313-M85 For Trailer Running Gear, a stringent standard mandated by the Government to assure brake effectiveness and structural integrity of the components.
ISO/TS 16949:2002 certified
» Was redesigned with forward self-adjusting feature in June 1996.
» Was redesigned with a cast backing plate in May 2000 replacing the stamped version.
• Fits Dexter 12,000lb axles(with cast backing and 7 bolt flange)
• For use with a 12 1/4in inside diameter and 5in depth drum
• Shoes are 5in wide
• Self-adjusting
• Left hand(driver's side)
• Complete assembly ready to install
Alternate Item Numbers
B1212E-21L-RED, EB01-160
Brake Type | Electric Brake |
---|---|
Brake Adjustment Type | Forward Self-Adjust |
Brake Size | 12-1/4in x 5in |
Axle Capacity Rating Per Pair | 16K |
Brake Orientation | Left Side |
Brake Backing Plate Mounting Bolt Holes | 7 |
Brake Mounts To | Axle Brake Flange / Spindle |
Brake Magnet Shape | Oval |
Brake Backing Plate Material | Steel |
Brake Backing Plate Finish | Painted |
Brake Shoes / Pads Material | Semi-metallic |
Brake Backing Plate Color | Black |
Mounting Hardware | Included |
Package Type | Retail Packaged |
Package Height | 5.25 inches |
Package Width | 12.5 inches |
Package Length | 12.5 inches |
Weight | 17 Lbs |
Dexter Reference#: 188931
Product ID#: 6663
