Dexter 9-28-1 Brake Drum for 12.25 Inch x 5 Inch Dexter 12K-15K Axles
This drum can be used with Dexter 12,000 lb and 15,000 lb hubs. Drum uses a brake assembly that measures 12 1/4" X 5". Hub and 7-244 mounting bolts are not included with the drum.
Product Specs
- Dexter Drum Only For 12K-15K Dexter Axles
- Oil Bath Hub Brake Drum ONLY!
- 3984 Inner / 28682 Outer Bearing
- Fits Dexter 12-15K Axles, RH & LH Side
- Capacity of 7,500 lbs. per each drum
- Drum Size: 12 1/4” x 5”
- Std stud length, for use w/steel wheels
Prop. 65 Warning for California Residents
WARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
Determining the Bolt Pattern
The first number in the bolt pattern is the number of bolt holes. The second number denotes the diameter, in inches, of the circle on which the bolt holes sit.
On wheels with an even number of bolt holes, measure from the center of one bolt hole to the center of the hole directly across from it. (Example: 8 on 6-1/2 means 8 bolt holes with 6-1/2" from the center of one hole to the center of another on the opposite side.)
To determine the bolt-circle diameter on wheels with an odd number of bolt holes, measure from the center of any bolt hole to the point halfway between the two bolt holes directly across from the first. (Example: 5 on 4-1/2 means 5 bolt holes with 4-1/2" measured to a point halfway between the opposite bolt holes.)
Measuring the distance (D) from the center of one bolt hole on the wheel to the center of a bolt hole right next to it can also help to determine the bolt pattern.
- If D = 2-5/8", then the bolt pattern is 5 on 4-1/2"
- If D = 2-3/4", then the bolt pattern is 5 on 4-3/4"
- If D = 3", then the bolt pattern is 5 on 5"
- If D = 3-1/4", then the bolt pattern is 5 on 5-1/2"
